The light ANCHOR CAPSTAN is used for mooring and mooring of luxury ships, high-speed ships and military auxiliary ships. It has the characteristics of simple structure, easy operation, convenient maintenance and high efficiency. At the same time, it is driven by a motor to realize braking.
The sprocket, drum and winch base of ANCHOR CAPSTAN are all precision cast. Compared with general anchor winches, it has small size, light weight (about 50% of general anchor winches), and high efficiency (up to 90%) ﹑Simple structure, easy operation, convenient maintenance and other characteristics.
Structural principle Light ANCHOR CAPSTAN is composed of electric motor, reducer, base, sprocket, winch body, jaw clutch, brake device, push rod, etc.
ANCHOR CAPSTAN is firmly connected to the deck through six bolts on the base.
The ANCHOR CAPSTAN motor is inserted at the input end of the reducer and is connected to the reducer as a whole. The sprocket shaft is directly sleeved on the output shaft of the reducer, and the torque is transmitted through the key.
The sprocket and the winch body are provided with inlays used as clutches, and the clutch handle 2 controls the lifting of the winch body, so that the winch body and the sprocket are combined or disconnected.
When the winch body and the sprocket teeth are engaged, the anchoring operation can be carried out, and when the two are disconnected, the cable winching operation can be carried out.
In the absence of electricity, the capstan can be opened, and the clutch nut can be turned to disengage the capstan body from the main shaft, allowing manual work such as anchoring and cable winching. The brake device is an ordinary band brake, which is composed of brake band, trapezoidal screw, nut, pin and other parts. When working, the handwheel is turned and transmitted to the brake band through the trapezoidal screw to achieve braking.
Although the price of metal will continue to rise in 2021, Taixing Expansion Marine Equipment (EME) still fulfills its promise of high quality and low price, and continues to tailor ANCHOR CAPSTAN with customers from all over the world.
Taixing Expansion Marine Equipment (EME) is the professional designer, manufacturer and exporter of mooring winch, positioning winch, towing winch, anchor winch, diesel winch, electric windlass, hydraulic windlass, diesel windlass, electric capstan, hydraulic capstan, pneumatic capstan etc. Our products are mainly for scientific research vessel, navy vessel, working barge, tug, cargo vessel, oil tanker, offshore platform etc.
